42-23116-01 – HEAT SEQUENCER (SPST)
$38.26
The Rheem 42-23116-01 is a 24 VAC SPST heat sequencer designed for HVAC systems, facilitating the sequential activation of heating elements to enhance system performance and safety.
Only 6 left in stock
Description
Purpose and Functionality: The Rheem 42-23116-01 is a Single Pole Single Throw (SPST) heat sequencer designed for HVAC systems. It controls the sequential activation of heating elements and associated components, ensuring efficient and safe operation of electric furnaces and heat pumps.
Key Features:
- Coil Voltage: 24 VAC
- Contact Configuration: SPST (Single Pole Single Throw) Normally Open
- Timing Specifications:
- On Timing: 1-30 seconds
- Off Timing: 40-110 seconds
- Electrical Ratings:
- Resistive Load at 120V: 25 Amps
- Resistive Load at 240V: 25 Amps
- Motor Load at 120V: 14 Full Load Amps (FLA), 72 Locked Rotor Amps (LRA)
- Motor Load at 240V: 7 Full Load Amps (FLA), 42 Locked Rotor Amps (LRA)
- Mounting: Angle bracket with two mounting holes
- Terminals: 1/4-inch quick connects
Usages for HVAC Repair: This heat sequencer is utilized in HVAC systems to:
- Control Heating Elements: Sequentially activates heating elements to prevent excessive electrical load during startup.
- Manage Blower Operation: Ensures the blower motor operates in sync with heating elements for optimal airflow.
- Enhance System Safety: Prevents simultaneous activation of all heating elements, reducing the risk of circuit overload.
Compatibility: The 42-23116-01 heat sequencer is suitable for various HVAC systems requiring a 24 VAC SPST sequencer. Verified compatible part numbers include:
- Rheem/Ruud/WeatherKing: 42-23116-01
- Protech: 42-23116-01
Always verify compatibility with your specific equipment model and specifications before installation.
Safety Considerations:
- Professional Installation: Ensure installation is performed by a qualified HVAC technician to maintain system safety and integrity.
- Electrical Safety: Disconnect power to the unit before performing any maintenance or replacements to prevent electrical hazards.
- Proper Handling: Handle the sequencer carefully to avoid damage to the electrical connections and internal components.
Additional Information: Regular inspection and maintenance of electrical components, including heat sequencers, are recommended to ensure safe and efficient operation. Using genuine OEM parts like the Rheem 42-23116-01 helps maintain system reliability and performance.
