SR1008-3W – SUPPLY REGISTER (10″ x 8″, 3-WAY, STAMPED FACE)
$13.95
TRUaire’s 103M1008 supply register measures 10″ x 8″, featuring a 3-way stamped steel face, white powder-coated finish, and an adjustable multi-shutter damper. Suitable for sidewall or ceiling installation in residential and commercial HVAC systems.
In stock
Description
The 103M1008 is a 10-inch by 8-inch supply register designed for sidewall or ceiling installation in HVAC systems. Manufactured by TRUaire, this register features a 3-way air deflection pattern with a stamped steel face, ensuring efficient airflow distribution.
103M1008 Supply Register (10″ x 8″, 3-Way, Stamped Face)
- Material: High-quality stamped steel
- Finish: White powder-coated for durability and aesthetic appeal
- Duct Opening Size: 10 inches (width) x 8 inches (height)
- Overall Dimensions: Approximately 11.75 inches (width) x 9.75 inches (height)
- Air Deflection: 3-way fixed air deflection pattern
- Fin Spacing: 1/2-inch spaced fins set at a 45-degree angle
- Damper: Equipped with a multi-shutter damper for airflow control
- Installation: Suitable for sidewall or ceiling mounting; includes countersunk screw holes for a flush appearance
Key Features:
- Durable Construction: Crafted from high-quality stamped steel with a white powder-coated finish, providing resistance to corrosion and ensuring longevity.
- Efficient Airflow Design: The 3-way fixed air deflection pattern, combined with 1/2-inch fin spacing at a 45-degree angle, ensures optimal distribution of conditioned air throughout the room.
- Adjustable Airflow Control: The integrated multi-shutter damper allows users to easily adjust and control the volume of airflow to suit individual comfort needs.
- Easy Installation: Designed for straightforward installation on sidewalls or ceilings, with countersunk screw holes that provide a clean and professional appearance.
Applications:
- Residential HVAC Systems: Ideal for use in home heating and cooling systems to supply conditioned air efficiently.
- Commercial Buildings: Suitable for offices, retail spaces, and other commercial environments requiring effective air distribution.
Safety Considerations:
- Proper Sizing: Ensure the register dimensions match the duct opening to maintain system efficiency and prevent air leakage.
- Regular Maintenance: Periodically clean the register to prevent dust and debris buildup, which can obstruct airflow and reduce system performance.
- Secure Installation: Follow manufacturer guidelines for installation to ensure the register is securely mounted and operates safely.
Additional Information:
- Compatibility: Designed to fit standard duct openings measuring 10 inches by 8 inches.
- Product Code: 103M1008
