IGN00152 – HOT SURFACE IGNITOR (TRANE, AFTERMARKET, DIRECT, SSN087KS)

If your furnace won’t light or only clicks without igniting, the hot surface ignitor is usually the fix. This 120V silicon nitride ignitor is a direct replacement for Trane and American Standard furnaces using IGN00152 or IGN00146.

Replaces: IGN00152, IGN00146, IGN0152, IGN0146, IGN152, IGN146, IGN-110-101, D156805, SSN087KS

Fits: Trane: TUD2C100B9V5VB, TUD2C100B9V5VBB; and other Trane/American Standard furnaces.

Need help? See our Furnace Not Heating Guide.

In stock at Open To Public HVAC Parts in Dallas. We test parts at the counter before you buy. Call or text (214) 340-9421.

Specs

• StyleHot surface ignitor (HSI)
• ElementSilicon carbide
• ConnectorVerify with existing part
• MountBracket style
• FitsTrane-compatible

Cross-reference numbers

This part replaces the following OEM and aftermarket numbers:

• D156805
• IGN-110-101
• IGN00146
• IGN00152
• IGN0146
• IGN146
• IGN152
• SSN087KS
• TUD2C100B9V5VB

Not sure if your number matches? Call (214) 340-9421 or bring the old part in — bench-testing is free.

Fits these models

• TUD2C100B9V5VBB

How do I test a hot surface ignitor?

Pull it out, check resistance with a multimeter across the leads. Healthy HSIs read roughly 40-90 ohms (80V) or 40-200 ohms (120V). Open circuit = dead. Bring it to the counter — we test these free.

Why does my new HSI keep failing?

HSIs fail from cycle stress and contamination. Common causes: dirty filter (overheats furnace, short-cycles), dirty flame sensor (forces re-light attempts), oversized furnace, or skin oils on the ceramic element. Fix the root cause when you replace.

How long should an HSI last?

3-7 years typical. Short-cycling burns through HSIs fast — address what's causing the short-cycling, not just the burned ignitor.
